COMPENSATION LINE PRINTER, 3 - CHANNEL
|
|
COMPENSATION LINE PRINTER, 3 - CHANNEL |
|
|
type. 0207 | |
| dimension: | 144 x 144 mm for mounting in cutout | |
| meas. areas: | 0 ... 1 mA to 100 mA 0.....5 mV to 100 V 0.....5 V to 10 V Fe-CuNi: 0....100°C to 900°C NiCr-NiAl: 0....150°C to 1300°C PtRh10-Pt 0... 1200°C to 1800°C Pt100/1,3850: -50 ... + 650 °C |
|
| showing precision: | 0.5 % | |
| display precision: | 1% | |
| paper speed: | 10, 20, 60, 120, 300, 600,
1200, 3600 mm/h or 5, 10, 20, 60, 120, 300, 600 mm/h |
|
| power supply: | 220 V , 50 Hz | |
| manufacturer: | LUMEL |
