Fluid and air temperature sensor with torsional part

REGULATOR'S WORKING DESCRIPTION




For zoom click on image


Working description:

Electronic regulator (3), with outer temperature sensor (2) and temperature sensor in supply pipe(1), is adjusting the water temperature to the current outer temperature by projected characteristic. Regulator with build-in programable watch makes possible that the water temperature is reduce by night.

For zoom click on image


Working description:

Electronic regulator (3), with outer temperature sensor (2) and temperature sensor in supply pipe(1), is adjusting the water temperature to the current outer temperature by projected characteristic. With remote-controlled programator (6) setting of the wanted temperature for daily or nightly working regime is possible.

For zoom click on image


Working description:

Electronic regulator (3), with temperature sensor in room (2) and pipe temperature sensor (1), compares the current water temperature with the room temperature. The room temperature can be adjusted via temperature sensor for rooms.

For zoom click on image


Working description:

Temperature sensor build in remote-controlled programator (2) detects room temperature, and electronic regulator (3) compares it with supply pipe temperature, which is detected by fluid temperature sensor (1).With remote-controlled programator (2) setting of the wanted temperature for daily or nightly working regime is possible.
